How to Set Up VLAN and Use LPB Piso WiFi Pause Time on Newifi 3 D2 and Linksys EA6900

LPB Piso WiFi is a coin-operated internet vending system widely used across the Philippines, known for its flexibility, remote control, and ease of use. Whether you’re a user trying to pause your internet time or a vendor managing your machine via the admin panel or app, this guide offers a detailed breakdown of how LPB Piso WiFi functions, without the fluff.

Pause Time Feature: How It Works and When to Use It

The Pause Time feature allows users to temporarily halt their internet session without losing remaining time. This is useful for brief interruptions, allowing users to resume service without needing to pay for unused minutes.

Steps to Pause or Resume Time:

• Connect to the LPB Piso WiFi network.
• Open a browser and go to: http://10.0.0.1
• Click Pause Time to suspend the session.
• Click Resume Time when ready to continue.

Note: This feature may be disabled by the administrator. Admins can toggle it on/off via the control panel under "Portal Settings."

Admin Panel Access: Managing Your Piso WiFi Network

The admin panel provides machine owners with complete control over the LPB Piso WiFi unit, including pricing, session control, voucher generation, and pause time settings.

Access Instructions:

• Open: http://10.0.0.1/admin
• Default Credentials:
  • Username: admin
  • Password: 123456789

Key Admin Functions:

• Enable/disable pause time
• View sales and transaction logs
• Set pricing and session durations
• Generate or manage access vouchers
• Perform license activation or renewal

For best results, access the admin panel via a desktop or tablet browser connected to the same network.

License Activation: Setting Up or Renewing Your Access

A valid license is required for full system functionality. Licenses are typically provided by authorized vendors.

How to Activate:

• Log in to the admin panel at http://10.0.0.1/admin
• Navigate to License Settings
• Enter your license key
• Click Activate or Save

Ensure your device has internet access during activation. If errors occur, verify your key or contact support.

LPB Piso WiFi Mobile App: Remote Management on the Go

Available on Android, the LPB Piso WiFi app enables machine owners to manage operations remotely and conveniently.

Download Link:

Google Play Store – LPB Piso WiFi App

App Features:

• View, add, or remove machines
• Activate or renew licenses
• Send credit remotely to machines
• Manage user accounts and profiles
• Access purchase options for additional tools or credits

The app is designed for vendors, not end-users. Clients must still access the pause/resume functions via the browser.

Router Compatibility and VLAN Setup

LPB Piso WiFi is compatible with various routers, especially those running OpenWRT or DD-WRT firmware. Proper VLAN configuration is necessary for session control and metering.

Supported Routers:

• Newifi 3 D2
• Linksys EA6900 v1.1

Video Guides for Setup:

Newifi 3 D2 VLAN Setup (OpenWRT)

1. Access Router: Go to http://192.168.1.1, log in via the OpenWRT interface.

2. Create VLANs:

• VLAN 20: WAN (CPU + WAN port)
• VLAN 30: Piso LAN (CPU + LAN ports)

3. Set Interfaces:

• PisoWAN: DHCP Client on VLAN 20
• PisoLAN: Static IP 10.0.0.1/24 on VLAN 30

4. Firewall: Allow forwarding from PisoLAN to WAN.

5. Upload LPB Files: Install firmware/portal, then reboot.

Linksys EA6900 VLAN Setup (DD-WRT)

1. Flash DD-WRT: Access http://192.168.1.1.

2. VLAN Config:

• VLAN 1: LAN (Ports 1–4)
• VLAN 2: WAN (Port 0)
• Optional VLAN 3 for Piso clients.

3. Bridge Setup:

• Create br1, assign VLAN (e.g. eth0.3)
• Set IP 10.0.0.1, enable DHCP.

4. Install LPB Portal: Upload or redirect to the LPB landing page.

Troubleshooting & Common Issues

LPB Piso WiFi offers more than just basic connectivity—it provides a fully customizable, time-metered internet platform ideal for public hotspots and small businesses. With features like pause time, admin control, remote management via app, and flexible router compatibility, it's a practical solution for monetized WiFi access.

For users, knowing how to pause time effectively can maximize session value. For operators, understanding admin and setup tools ensures reliable service and easier troubleshooting.
